HB-1000S Hex Head Bolt
HB-3100S TOGGLE PIN STEEL METRIC
| HB-1000MSS | |||||
| HEX HEAD BOLT | |||||
| STAINLESS STEEL | |||||
| INCH | |||||
| PART NUMBER | A | B | C | D | E |
| HEX BOLT DIAMETER AND THREAD | BOLT LENGTH | HEAD THICKNESS | HEAD DIAMETER | THREAD LENGTH | |
| HB-1000MSS-10X40 | 10mm-1.5 | 40mm | 6.4mm | 17mm | 26mm |
| HB-1000MSS-10X50 | 10mm-1.5 | 50mm | 6.4mm | 17mm | 26mm |
| HB-1000MSS-10X60 | 10mm-1.5 | 60mm | 6.4mm | 17mm | 26mm |
| HB-1000MSS-10X70 | 10mm-1.5 | 70mm | 6.4mm | 17mm | 26mm |
| HB-1000MSS-10X80 | 10mm-1.5 | 80mm | 6.4mm | 17mm | 26mm |
| HB-1000MSS-12X40 | 12mm-1.75 | 40mm | 7.5mm | 19mm | 30mm |
| HB-1000MSS-12X50 | 12mm-1.75 | 50mm | 7.5mm | 19mm | 30mm |
| HB-1000MSS-12X60 | 12mm-1.75 | 60mm | 7.5mm | 19mm | 30mm |
| HB-1000MSS-12X70 | 12mm-1.75 | 70mm | 7.5mm | 19mm | 30mm |
| HB-1000MSS-12X80 | 12mm-1.75 | 80mm | 7.5mm | 19mm | 30mm |
| HB-1000MSS-14X40 | 14mm-2.0 | 40mm | 8.8mm | 22mm | 34mm |
| HB-1000MSS-14X50 | 14mm-2.0 | 50mm | 8.8mm | 22mm | 34mm |
| HB-1000MSS-14X60 | 14mm-2.0 | 60mm | 8.8mm | 22mm | 34mm |
| HB-1000MSS-14X70 | 14mm-2.0 | 70mm | 8.8mm | 22mm | 34mm |
| HB-1000MSS-14X80 | 14mm-2.0 | 80mm | 8.8mm | 22mm | 34mm |
| HB-1000MSS-16X40 | 16mm-2.0 | 40mm | 10mm | 24mm | 38mm |
| HB-1000MSS-16X50 | 16mm-2.0 | 50mm | 10mm | 24mm | 38mm |
| HB-1000MSS-16X60 | 16mm-2.0 | 60mm | 10mm | 24mm | 38mm |
| HB-1000MSS-16X70 | 16mm-2.0 | 70mm | 10mm | 24mm | 38mm |
| HB-1000MSS-16X80 | 16mm-2.0 | 80mm | 10mm | 24mm | 38mm |
| HB-1000MSS-18X40 | 18mm-2.5 | 40mm | 11.5mm | 27mm | 42mm |
| HB-1000MSS-18X50 | 18mm-2.5 | 50mm | 11.5mm | 27mm | 42mm |
| HB-1000MSS-18X60 | 18mm-2.5 | 60mm | 11.5mm | 27mm | 42mm |
| HB-1000MSS-18X70 | 18mm-2.5 | 70mm | 11.5mm | 27mm | 42mm |
| HB-1000MSS-18X80 | 18mm-2.5 | 80mm | 11.5mm | 27mm | 42mm |
| HB-1000MSS-20X40 | 20mm-2.5 | 40mm | 12.5mm | 30mm | 46mm |
| HB-1000MSS-20X50 | 20mm-2.5 | 50mm | 12.5mm | 30mm | 46mm |
| HB-1000MSS-20X60 | 20mm-2.5 | 60mm | 12.5mm | 30mm | 46mm |
| HB-1000MSS-20X70 | 20mm-2.5 | 70mm | 12.5mm | 30mm | 46mm |
| HB-1000MSS-20X80 | 20mm-2.5 | 80mm | 12.5mm | 30mm | 46mm |
